Davit Launched Inflatable Liferaft
product Parameter (specification)
| Life Raft | |||
| Trademark | new maritime |  |
|
| Type | Life Raft | ||
| Specification | 2-30person, customizable | ||
| Lighting System | 1 Interior Lighting Lamp, 1 Exterior | ||
| Suitable for | Adult and Children | ||
| Material | Neoprene Coated Fabric, Water-Proof | ||
| Stowage Height | 18-50m From Water Surface | ||
| Ballast System | 4 X 60.5L Water Pockets | ||
| Stowage Height | 18-50m From Water Surface | ||
| HS Code | 8907100000 | ||
| Production Capacity | 500000/Year | ||
| Delivery Time | 15-30 Days | ||
| Transport Package | Knitting Bag or Wooden Case | ||
SOLAS approved 4-35 persons Self Inflatable LifeRaft
the specification of the HSR-YJ SOLAS throw overboard liferaft
Lt Suitable for installing in the vessels sailing on international voyages.
It meet the China MSA-"Regulations fot the Statutory of Ships and off shore Installations---Technical Regulations for the Statutory Surveys of Sea-going Ships Engaged in Domestic Voyages"2004, and it's 2008 Amendments, Part4,Ch,3, and SOLAS(74/96), LAS, MSC.81(70),MSC.226(82),MSC.218(82),MSC.293(87),MSC.323(89).ISO15738(2002).
Max.Storage Height:18-50m
Equipment Outfit: HSC PACK
Certificates: CCS,GL
Diffrent type
|
Type |
ADL-12 |
ADL-15 |
ADL-16 |
ADL-20 |
ADL-25 |
|
|
Shape |
rectangular octagon |
long decagonal |
rectangular dodecagon |
|||
|
Capacity (Persons) |
12 |
15 |
16 |
20 |
25 |
|
|
Dimensions (L×W×H) (mm) |
2983×2903×1450 |
3310×3220×1550 |
3392×3302×1650 |
3986×3710×1850 |
4225×4065×2000 |
|
|
shackle position height(mm) |
1600 |
1700 |
1800 |
2000 |
2200 |
|
|
Cylinder (L) |
5L×2 |
6L×2 |
6L×2 |
9L×2 |
12L×2 |
|
|
Max. storage height(m) |
18~36 |
|||||
|
Container dimension(mm) |
SOLAS A PACK (a×b) |
1350×Φ660 |
1550×Φ660 |
1550×Φ660 |
1600×Φ780 |
1680×Φ780 |
|
SOLAS B PACK (a×b) |
1350×Φ660 |
1350×Φ660 |
1350×Φ660 |
1550×Φ660 |
1600×Φ780 |
|
|
Packaging dimension(mm) |
SOLAS A PACK (c×d×e) |
1410×720×770 |
1610×720×770 |
16110×720×770 |
1660×840×890 |
1740×840×890 |
|
SOLAS B PACK (c×d×e) |
1410×720×770 |
1410×720×770 |
1410×720×770 |
1610×720×770 |
1660×840×890 |
|
|
Requied bollard pull(kN) |
For 2knot speed |
1.08 |
1.25 |
1.28 |
1.35 |
1.46 |
|
For 3knot speed |
2.04 |
2.48 |
2.52 |
2.65 |
3.02 |
|
|
(kg)Weight |
≤145 |
≤180 |
≤185 |
≤220 |
≤230 |
|
Davit Launched Inflatable Liferaft
Davit Launched Inflatable Liferaft also be called Davit Launched Self-righting Inflatable Life Raft. It is a safety device specifically designed for ships, mainly used for personnel evacuation and rescue in emergency situations. The Davit Launched Inflatable Liferaft uses a Davit system to quickly release and inflate the life raft from its storage position, ensuring quick use in emergency situations. After falling into the water, the life raft can automatically inflate without manual operation, saving valuable time. Capable of carrying 4 to 12 people, providing sufficient space and buoyancy to ensure the safety of all passengers. Using high-strength PVC waterproof material, it can withstand harsh marine environments. Equipped with first aid kit, fresh water, food, signal equipment, etc,.
Our Davit Launched Inflatable Liferafts complies with SOLAS 1974/96, LAS, MSC81(70), and MSC226(82) regulations.
Related products: Drop type inflatable type liferaft in yacht type U
Main Feature
Color: Orange
Material: PVC
Application: Drifting, swimming, and marine
Certificate: CCS, LR
Specification
|
Size |
Color |
L(cm) |
W(cm) |
H(cm) |
|
4 persons |
orange |
500 |
200 |
300 |
|
6 persons |
orange |
500 |
200 |
300 |
|
8 persons |
orange |
500 |
200 |
300 |
|
10 persons |
orange |
500 |
200 |
300 |
|
12 persons |
orange |
500 |
200 |
300 |
|
contact us to get more info. |
||||
FAQ
Q: Are you a factory or a trading company?
A: We are trading and factory combo.
Q: How do you ensure the quality of your products?
A: Professional quality inspection department, on-site inspection of the production process, 3strict inspections before shipment.
Q: Are there any format and size requirements on customization?
A: Design modifications and customization are acceptable without compromising safety.
